Neptune 2.0 | Grid

Vandal resistant IP65 fitting

Versatile vandal-resistant fitting with a DC driver, flexible control solutions, 15-year protection against C5 corrosion and a low build-height.

Item no: 123975
Clear

Description

Neptune 2.0 Grid is a vandal-resistant quality fitting with a DC driver which provides flicker-free light. The DC driver also means that Neptune is available with both motion and twilight sensors.

Neptune 2.0 Grid has a slim design with the lowest build-height on the market. Small boxes make it easier to transport more fittings at one time. Painted versions are protected against C5 class corrosion for 15 years. The fittings are completely maintenance-free.

A unique LED module design ensures that the light surface is completely uniform, with no shadows or hotspots. The glossy diffuser prevents dirt from collecting on the surface and makes the fitting easier to clean.

Construction

A vandal resistant quality fitting in a circular shape, body made of high pressure die-cast aluminium, décor in polycarbonate. The fitting is powder painted, white RAL 9016, black RAL 9011 or titan RAL 9007. The front ring is fixed with 4 Torx screws in stainless steel which have been given a Delta seal treatment. IP65, IK10, class II. Radar, Twilight and DALI versions class I.

Sensor (Radar)

The sensitivity of the microwave motion sensor can be adjusted via DIP-switch. The hold time (duration of time the light is on after the last detection) can also be adjusted between 5 sec and 25 min. Radar versions can be used as Masters for other fittings. Master-Master or Master-Slave-Master configurations can also be used.

Photo cell (Twilight)

The sensor has a twilight function (2 – 30 lux). The desired lux level can be set via DIP-switch to match the environment. When used, the light stays off as long as the ambient natural light is above the set threshold. The light turns on when the amount of ambient light dips below the set threshold.

LightAdjust

Fittings marked with “LightAdjust” are equipped with a setting which makes it possible to set the preferred light level in 8 steps. By delivery the fittings are set on the highest level.

Application areas

Parking facilities, facades, entrance areas, stairwells, walkways, underpasses and more.

Technical description

Accessories

105289 Number plate White
111437 Number plate Black

Variant
123975
123976
123977
123978
123979
123980
123981
123982
123983
123984
123985
123986
123987
123988
123989
123990
123991
123992
123993
123994
123995
123996
123997
123998
Colour Control LightAdjust Colour temperature Effect fitting Luminous flux fitting Luminous efficiency fitting Insulation class Colour index Ra Colour tolerance MacAdam Life time h Weight
White No LightAdjust 3000K 8W 206 lm 26 lm/W II >70 4 L80B10 100.000 1,3 kg
Black No LightAdjust 3000K 8W 206 lm 26 lm/W II >70 4 L80B10 100.000 1,3 kg
Titan No LightAdjust 3000K 8W 206 lm 26 lm/W II >70 4 L80B10 100.000 1,3 kg
White No LightAdjust 4000K 8W 221 lm 28 lm/W II >70 4 L80B10 100.000 1,3 kg
Black No LightAdjust 4000K 8W 221 lm 28 lm/W II >70 4 L80B10 100.000 1,3 kg
Titan No LightAdjust 4000K 8W 221 lm 28 lm/W II >70 4 L80B10 100.000 1,3 kg
White Radar LightAdjust 3000K 8W 206 lm 26 lm/W I >70 4 L80B10 100.000 1,4kg
Black Radar LightAdjust 3000K 8W 206 lm 26 lm/W I >70 4 L80B10 100.000 1,4kg
Titan Radar LightAdjust 3000K 8W 206 lm 26 lm/W I >70 4 L80B10 100.000 1,4kg
White Radar LightAdjust 4000K 8W 221 lm 28 lm/W I >70 4 L80B10 100.000 1,4kg
Black Radar LightAdjust 4000K 8W 221 lm 28 lm/W I >70 4 L80B10 100.000 1,4kg
Titan Radar LightAdjust 4000K 8W 221 lm 28 lm/W I >70 4 L80B10 100.000 1,4kg
White Twilight LightAdjust 3000K 8W 206 lm 26 lm/W I >70 4 L80B10 100.000 1,4kg
Black Twilight LightAdjust 3000K 8W 206 lm 26 lm/W I >70 4 L80B10 100.000 1,4kg
Titan Twilight LightAdjust 3000K 8W 206 lm 26 lm/W I >70 4 L80B10 100.000 1,4kg
White Twilight LightAdjust 4000K 8W 221 lm 28 lm/W I >70 4 L80B10 100.000 1,4kg
Black Twilight LightAdjust 4000K 8W 221 lm 28 lm/W I >70 4 L80B10 100.000 1,4kg
Titan Twilight LightAdjust 4000K 8W 221 lm 28 lm/W I >70 4 L80B10 100.000 1,4kg
White DALI No 3000K 8W 206 lm 26 lm/W I >70 4 L80B10 100.000 1,3 kg
Black DALI No 3000K 8W 206 lm 26 lm/W I >70 4 L80B10 100.000 1,3 kg
Titan DALI No 3000K 8W 206 lm 26 lm/W I >70 4 L80B10 100.000 1,3 kg
White DALI No 4000K 8W 221 lm 28 lm/W I >70 4 L80B10 100.000 1,3 kg
Black DALI No 4000K 8W 221 lm 28 lm/W I >70 4 L80B10 100.000 1,3 kg
Titan DALI No 4000K 8W 221 lm 28 lm/W I >70 4 L80B10 100.000 1,3 kg
