AutoSwitch priority circuit power distributer, front

AutoSwitch, priority circuit

Priority power distributer

The autoswitch priority circuit ensures that power is always drawn from the mains inlet when the vehicle is connected to both the mains and an inverter.

Art. nr: 703697

Description

The AutoSwitch ensures that the mains inlet has priority over the inverter when both are connected. This ensures that that the inverter does not use power from the batteries when the vehicle is connected to the mains. The AutoSwitch also has a security feature that ensures that no power in transferred from the mains inlet when only the inverter is in use.

Technical description

DEFA AS conforms to the requirements of both ISO 9001- 2008, ISO 14001:2004 and OHSAS 18001:2007. In addition, our engine heaters and cables conform to the requirements of ISO/TS 16949:2002.

Input voltage
Output voltage
Constant operation limit
Max. output power
Fuse
IP rating
230V, 50Hz (±10%)
230V AC
16A
3680W
16A/T250
IP44
